TechnicalResources
Access environmental test reports, fire testing data, certifications, and product literature for all AFT fire safety solutions.
Fire Testing: ASTM Tests
Third-party fire test reports for AFT's coatings and inhibitors. Grouped by product, organized by lab and standard.
Fire Inhibitor
Fire Defense Coating 2.0
Fire Defense Coating 3.0
Documents & Downloads
Download technical documents, test reports, and product literature. All documents are available as PDF or printable HTML.
Environmental Testing
Nautilus Toxicity Report — Daphnia magna
NewIndependent environmental toxicity testing by Nautilus Environmental (ISO/IEC 17025 accredited). AFT Fire Inhibitor tested per Environment Canada EPS 1/RM/11. Result: LC50 >1000 mg/L — classified as nontoxic.
Nautilus Toxicity Report — Rainbow Trout
NewIndependent environmental toxicity testing by Nautilus Environmental (ISO/IEC 17025 accredited). AFT Fire Inhibitor tested per Environment Canada EPS 1/RM/9. Result: LC50 616 mg/L (95% CI: 517–734 mg/L) — classified as low toxicity.
Safety & Technical Data Sheets
Download the SDS and TDS for every AFT product. All sheets are formatted to OSHA HCS / GHS standards and include independent lab references.
Safety Data Sheets (SDS)
Technical Data Sheets (TDS)
See AFT In Action
Live demonstrations from the field — every product, tested on real materials and real fires.
Fire Inhibitor — Demo
Direct ignition test on treated lumber — flame contact, char depth, and self-extinguishing behavior.
Fire Defense Coating — Demo
Class A intumescent coating on OSB and plywood — flame spread + smoke development.
Fire-Extinguishing Wetting Agent — Demo
Knockdown test against open-flame fuel fire — surfactant + cooling action.
Home Protection Solution — Demo
AFT Fire Inhibitor applied to structural members and landscaping in a wildfire defense scenario.
Fire Standard Tests
Full results from independent fire standard testing — flame spread, smoke development, time to ignition, and Class A / ASTM E2768 qualification by lab and test number.
| Product | Test | Material | Flame Spread Index (<25 for Class A) | Smoke Spread Index (<450 for Class A) | Ft Flame Traveled in 10 min (<10.5 ft for Class A) | Ft Flame Traveled in 30 min (<10.5 ft for ASTM E2768) | Time to Exceed 10.5 ft | Time to Ignition | Class A | ASTM E2768 | Testing Lab | Test Number | Date |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Fire Defense Coating 2.0 | ASTM E84 / E2768 | Gypsum | 0 | 5 | 0 ft | 0 ft | Did not exceed | 00m:00s | Yes | Yes | SGS Labs | 3-57888-0 | Oct 2024 |
| Fire Defense Coating 2.0 | ASTM E84 | Plywood | 5 | 40 | 7 ft 5 in | N/A | N/A | 05m:07s | Yes | No | SGS Labs | 3-57886-0 | Oct 2024 |
| Fire Defense Coating 2.0 | ASTM E84 | OSB | 5 | 60 | 3 ft 1 in | 18 ft 7 in | N/A | 04m:07s | Yes | No | SGS Labs | 3-57887-0 | Oct 2024 |
| Fire Defense Coating 2.0 | ASTM E84 | MDF Siding; 18 yrs old; Louisville CO | 15 | 50 | 4 ft 3 in | N/A | N/A | 00m:45s | Yes | No | SGS Labs | 3-59192-0 | Apr 2025 |
| Fire Defense Coating 3.0 | ASTM E84 / E2768 | Cedar | 10 | 5 | 2 ft 1 in | 5 ft 3 in | Did not exceed | 00m:30s | Yes | Yes | SGS Labs | 3-59474-0 | May 2025 |
| Fire Defense Coating 3.0 | ASTM E84 / E2768 | LVL Siding | 20 | 0 | 4 ft 1 in | 6 ft 4 in | Did not exceed | 00m:37s | Yes | Yes | SGS Labs | 3-59473-0 | May 2025 |
| Fire Defense Coating 3.0 | EN 13823 (Euroclass A2/s1/d0) | Calcium Silicate | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | Thomas Bell Wright | ZL077-1 | Feb 2026 |
| Fire Inhibitor 1.0 | ASTM E84 | Red Oak | 25 | 5 | 8 ft 2 in | N/A | N/A | 01m:53s | Yes | No | Gov Mark | 3-19871-0 | Jun 2017 |
| Fire Inhibitor 2.0 | ASTM E84 / E2768 | Doug Fir | 5 | 35 | 2 ft | 8 ft 10 in | Did not exceed | 02m:28s | Yes | Yes | SGS Labs | 3-62450-0 | May 2026 |
Swipe horizontally to view all columns.
Testing & Certification for FINC Products and Coatings — Class A
Definitions: AFT (AF Tech USA Ltd); FAR (Federal Aviation Regulations); FAA-DER (Designated Engineering Representative); PPE (Personal Protection Equipment, incl. garments)
Environmental Safety Verified
AFT's Fire Inhibitor has been independently tested by Nautilus Environmental under ISO/IEC 17025 accreditation. The Daphnia magna test returned LC50 >1000 mg/L (nontoxic) and the Rainbow Trout test returned LC50 616 mg/L (low toxicity). Our products are free of PFAS, fluorine, halogens, and bromides — safe for humans, animals, and the environment.
Need Additional Technical Data?
Contact our team for custom submittal packages, SDS sheets, specification guidance, or testing information specific to your application.
